Specification

Volts：12V

Amps：80A

Adjustment Hole：8

Pivot Hole (mm)：10

Adjustment To Pivot (mm)：165

Pivot Length (mm)：58

Inside Foot To Foot (mm)：NA

Pulley (mm)：62

No Of Grooves：4PV

Plug：RP11



OEM Part number

27060-62160 27060-62160-84 27060-62180 27060-62190 2706062160 270606216084 2706062180 2706062190 101211-0951 101211-0952 101211-4132 101211-9590 102211-5040 102211-5041 102211-5042 1012110951 1012110952 1012114132 1012119590 1022115040 1022115041 1022115042 114362 13794 HX206



Fitment

Fit For Toyota Landcruiser Prado 90 Series VZJ95 V6 engine 5VZ-FE 3.4L Patrol 1996-2002

Fit For Toyota Landcruiser Prado VZJ95R 3.4L V6 Petrol - 5VZ-FE 06/1996 - 09/2002

Fit For Toyota Hilux VZN167, 172 V6 engine 5VZ-FE, 5VZ4E 3.4L Patrol 2002-2003

Fit For Toyota 4-Runner VN007 V6 engine 3VZ-E 3.0L Patrol 1988-1992(around plug need a adapter)

Fit For Toyota 4-Runner V6 engine 3VZ-E 3.0L Patrol 1992-1995

Fit For Toyota Hilux Surf VZN185 3.4L V6 Petrol - 5VZ-FE 11/1995 - 10/2002

Fit For Toyota Hilux VZN167R 3.4L V6 Petrol - 5VZ-FE 08/2002 - 01/2005

Fit For Toyota Hilux VZN172R 3.4L V6 Petrol - 5VZ-FE 08/2002 - 01/2005



Package

1 x Alternator
